Single Phase 3 channel data logger Model SEM260

App service:  Android  "mywatt30"
Modubus RS-485 software for CRT5000  : We supply free for the buyer.  http://mywatt.biz/crt5000
Web cloud service sample:  http://mywatt.biz/cloud

Model Specification Scope of Supply Price Photo
SEM260-30A Wireless transmitter
424MHz
427MHz
433MHz

Current measurement up to 30A

Measuring item:
Voltage, Current, P, Q, S, Wh, VAh, varh, Frequency, Power factor,

RS-485, usb

　

 3pcs of 30A clamp



Option:
1)Temperature & Humidity sensor


2)485->usb converter
 		 　
SEM260-75A Wireless transmitter
424MHz
427MHz
433MHz

Current measurement up to 75A

Measuring item:
Voltage, Current, P, Q, S, Wh, VAh, varh, Frequency, Power factor,

RS-485, usb 		3pcs of 75A clamp



Option:
1)Temperature & Humidity sensor

2)485->usb converter		 　
SEM260-200A Wireless transmitter
424MHz
427MHz
433MHz

Current measurement up to 200A

Measuring item:
Voltage, Current, P, Q, S, Wh, VAh, varh, Frequency, Power factor,

RS-485, usb 		3pcs of 200A clamp



Option:
1)Temperature & Humidity sensor

2)485->usb converter		 　
SEM260-500A Wireless transmitter
424MHz
427MHz
433MHz

Current measurement up to 500A

Measuring item:
Voltage, Current, P, Q, S, Wh, VAh, varh, Frequency, Power factor,

RS-485, usb 		3pcs of 500A clamp




Option:
1)Temperature & Humidity sensor

2)485->usb converter
